Tuning Menu Stage
I
|
|
<
Feature >
In the first step of the tuning
process, the VX-ROM will release
the true potential of the GT-R's
performance, while removing the
speed limiter, resetting the
injection/ignition timing as well
as increasing the boost pressure
by 0.1-0.2 bar whilst still
maintaining the reliability and
drivability offered by the
factory ECU.
|
|
|
Tuning Menu Stage
II
|
|
<
Feature >
First designed to increase
performance and response
throughout the rev range, this
exhaust system offers
uncompromised quality and
durability, as well as meeting
the current regulations.
|
|
|
Tuning Menu Stage
III
|
|
<
Feature >
Just when you were beginning to
think youfd upgraded all your
intake piping, the Minefs intake
system is wide open reducing
intake airflow resistance and
thus increasing throttle response
and horsepower. Combine with
Minefs Intercooler Hard Pipe Kit
and Titanium Suction Pipe Kit for
even better effect and
performance.
|
|
|
Tuning Menu Stage
IV
|
|
<
Feature >
Ultimate tuning specifications
for street use to release the
full potential and throttle
response of the GT-R while
retaining the drivability and
reliability considering the
environment.
|
|
|
|
|
Menu
|
Injector
+
Delivery Pipe
|
Fuel Pump
|
Boost
pressure
(kgf/cm2)
|
Boost
pressure
(kpa)
|
Boost
pressure
(bar)
|
Boost
pressure
(psi)
|
Horsepower
(PS)
Gain
Note I
|
Feature
|
Spex-X
6.0 Kit
+
Intake
/ Exhaust system
utilizing
Mine's Super Catalyzer II
Note II
|
Standard
|
Standard
|
1.2
|
118
|
1.18
|
17.1
|
540-560
|
Utilizing the catalytic
converters to protect the environment, the
ultimate throttle response of Spec-X 6.0
Kit can be gained.
|
Spex-X
6.0 Kit
+
Intake / Exhaust system
|
Standard
|
Standard
|
1.2
|
118
|
1.18
|
17.1
|
580-600
|
Basic
package for the ultimate response and
power mainly for track use while
maintaining the reliability and filling
efficiency of original VR38DETT Engine.
|
Spex-X
6.0 Kit
+
Intake
/ Exhaust system
|
650cc~6
+
Delivery pipe
|
Standard
|
1.3
|
127
|
1.27
|
18.5
|
600-620
|
As the
boost pressure is increased, supporting
fuel modifications are basically mandatory
to be able to provide enough fuel into the
mix to safely support the airflow. The
whole setup is assuredly 100% compatible
with the Minefs VX-ROM ECU
upgrade.
|
Spex-X
6.0 Kit
+
Intake
/ Exhaust system
+
Camshaft
|
650cc~6
+
Delivery pipe
|
Standard
Note III
|
1.3
|
127
|
1.27
|
18.5
|
620-630
|
The
Mine's camshaft is a full camshaft
replacement for the VR38DETTdesigned to
unleash the full potential of the engine
in terms of response and power at mid to
high rev range, while it will ideally
breath better without turbines modified.
|
Spex-X
6.0 Kit
+
Intake
/ Exhaust system
+
Camshaft
+
Modified Stock Turbine
|
800cc~6
+
Delivery pipe
|
265L/h x 2
Bolt-on
Pump Kit
|
1.5
|
147
|
1.47
|
21.3
|
700
|
The
Mine's turbos are bolt on affair without
sacrificing the low speed range to
increase the power at mid to high rev
range while modified based on the stock
turbos by changing the full flow turbos
and ball bearing ones. These also would
ideally suit someone considering camshaft
upgrades to further enhance the response
and power.
|
Spec-X
6.0 Kit
Contents: VX-ROM
Type-X ECU, Reinforced
Actuator, Spark Plug,
Electronic Boost
Controller, Super Outlet
Pro II, Straight
Converter, Induction
Support & Hose
clamp
|
|
|
Note
IF
|
The horsepower
shown can not be guaranteed.
Please use this number as just
for your reference. Furthermore,
depending on the gasoline octane
rate, the maximum horsepower
would vary.
|
Note
IIF
|
The
specifications here show the
Spec-X 6.0 Kit while the Super
Outlet Pro II and Straight
Converter are replaced with the
sports catalyzers with catalytic
converters.
|
Note
IIIF
|
The fuel pump
replacement is additionally
required depending on the
vehicle.
|
|
*
|
The boost
pressure amount shown is the
maximum one when it stables, and
is rounded off to the nearest
whole number.
@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@
|
|
Boost Pressure
(kgf/cm2)
|
¨
|
After
conversion
|
Pressure
Unit
|
|
1.0
|
¨
|
98
|
kps
|
1.0
|
¨
|
0.98
|
bar
|
1.0
|
¨
|
14.2
|
psi
|
|
|
|
|
